UPS nJoy Aster 2K Power 2000 VA/1800 W Type On-line Nominal Input Voltage 208/220/230/240 VAC Accepted Input Voltage Range 80-300 VAC Nominal Output Voltage 208/220/230/240 VAC – user selectable Frequency 50 Hz/60 Hz Outlets Input 1 x IEC-320 C14 Output 8 x IEC-320 C13 Transfer Time to Battery / AC Zero Typical Backup Time 25% Load – 24min 4sec 50% Load – 12min 4sec 75% Load – 6min 10sec 100% Load – 4min 30sec Communication Ports HID USB / RS232 / EPO / SNMP Software http://www.powermonitor. software/ Battery Type Sealed and leak proof maintenance Efficiency High efficiency up to 97% Features Internal bypass EPO function Multifunctional color LCD Output Power Factor 0.9 Generator compatible ECO Mode for energy saving Software management Rack/Tower design Easy Battery Replacement External battery pack (optional) LCD Display UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions Environment 0- 40°C (non-condensing) Physical Dimensions 438 x 610 x 88 mm https://www.njoy.ro/ups-commercial/aster-2000#specificatii.
UPS nJoy Aster 2K Power 2000 VA/1800 W Type On-line – UPCMCOP920HASCG01B
SKU:
UPCMCOP920HASCG01B
Categorie: UPS
Descriere
Caracteristici
- USB Port: Yes
- Capacitate putere UPS: 1800W
- Product colour: Black
- Compliance certificates: CE, RoHS
- Manual: Yes
- LED indicators: Yes
- Operating temperature (T-T): 0 - 40 °C
- Cooling type: Active
- Power source type: AC
- Height: 88 mm
- Operating relative humidity (H-H): 0 - 90%
- Products per master (outer) case: 1 pc(s)
- Batteries included: Yes
- Serial ports quantity: 1
- ECO mode: Yes
- Display type: LCD
- Master (outer) case height: 231 mm
- Rack mount kit: Yes
- Tip UPS:: Online
- Form Factor:: Rackmount/Tower
- Capacitate Rack: 2U
- Ecran LCD:: Da
- Port USB: Da
- Number of input phases: 1
- Number of output phases: 1
- AC outlet types: C13 coupler
- Power plug: C14 coupler
- Serial interface: Yes
- Built-in fan: Yes
- Input operation voltage (max): 300 V
- Cold start: Yes
- Storage temperature (T-T): -15 - 45 °C
- Output operation voltage (max): 240 V
- Emergency Power Off (EPO): Yes
- AC outlets quantity: 8 AC outlet(s)
- Serial interface type: RS-232
- Form factor: Rackmount/Tower
- Rack capacity: 2U
- Auto-restart: Yes
- UPS topology: Double-conversion (Online)
- Crest factor: 3:1
- Waveform: Pure sine
- Input operation voltage (min): 80 V
- Output operation voltage (min): 208 V
- Output power: 1800 W
- Output power factor: 0.9
- Noise level: 50 dB
- Output power capacity: 2 kVA
- Input frequency: 40/70 Hz
- Output voltage regulation: ±1%
- Efficiency (ECO mode): 97%
- Output voltage Total Harmonic Distortion (THD): 5%
- Power protection features: Battery discharge, Overload
- Cables included: Input power cable, USB cable
- Width: 610 mm
- Depth: 438 mm
- Master (outer) case width: 550 mm
- Master (outer) case length: 746 mm
- Typical backup time at full load: 4.5 min
- Typical backup time at half load: 12.06 min
- Weight: 23.1 kg
- Master (outer) case gross weight: 24.5 kg
Informații suplimentare
Greutate | 24 kg |
---|---|
Dimensiuni | 75 × 55 × 22 cm |
Garanție |
36 luni |
