Placa de baza Sapphire PURE B850A WIFI – 52123-11-40G
1.297,00 lei
7 în stoc
Descriere
Placa de baza Sapphire PURE B850A WIFI.
Caracteristici
- PCI: 2
- Video-Connection: VGA/HDMI
- Wi-FI: Yes
- HDMI: 1
- Wireless: Da
- PCI-Ex16: 1
- Gaming: Nu
- Bluetooth: Nu
- Onboard-CPU: Yes
- HDMI: Da
- Component for: PC
- USB connector type: USB Type-A, USB Type-C
- Memory channels: Dual-channel
- Ethernet LAN: Yes
- HDMI ports quantity: 1
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- Processor manufacturer: AMD
- Thunderbolt: Nu
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 0
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 0
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
- USB 2.0 ports quantity: 4
- Audio output channels: 7.1 channels
- Line-in: Yes
- PCI Express x16 (Gen 5.x) slots: 1
- PCI Express x4 (Gen 4.x) slots: 1
- Audio Chip: Realtek ALC897
- Supported storage drive types: HDD & SSD
- DisplayPorts quantity: 1
- VGA (D-Sub) ports quantity: 0
- Sloturi memorie: 4
- Parallel processing technology support: Not supported
- DVI-D ports quantity: 0
- Windows operating systems supported: Windows 10 x64, Windows 11
- Model Chipset: B850
- Gaming: Nu
- Format: ATX
- Soclu Procesor: Socket AM5
- Tip Memorie: DDR5
- Numar sloturi memorie: 4
- Memorie maxima: 256 GB
- Tip slot interfata grafica: PCIe 5.0 x16
- Chipset audio integrat: Realtek
- Canale audio: 7.1
- Wireless: Da
- Bluetooth: Da
- USB Type C: Da
- HDMI: Da
- Thunderbolt: Nu
- Sloturi M.2: 3
- RJ-45 LAN: 1
- Number of memory slots: 4
- Memory slots type: DIMM
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 0
- Number of SATA III connectors: 4
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- Motherboard chipset family: AMD
- Supported memory types: DDR5-SDRAM
- Maximum internal memory: 256 GB
- Maximum internal memory per slot: 64 GB
- Number of storage drives supported: 7
- Front panel connector: Yes
- RGB LED pin header: Yes
- WiFi-AP antenna jack: 2
- Ethernet interface type: 2.5 Gigabit Ethernet
- Motherboard form factor: ATX
- Number of M.2 (M) slots: 3
- 1st M.2 highest PCI Express generation: 5.0
- 2nd M.2 highest PCI Express generation: 4.0
- 3rd M.2 highest PCI Express generation: 4.0
- Antenna included: Yes
- 12V power connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Serial port headers: 1
- Processor socket: Socket AM5
- Supported processor sockets: Socket AM5
- Supported memory clock speed (max): 8000 MHz
- Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
- Number of chassis fan connectors: 3
- LAN controller: Dragon RTL8125BG
- Motherboard chipset: AMD B850
- 1st M.2 largest key size: 2280
- 2nd M.2 largest key size: 2280
- 3rd M.2 largest key size: 2280
- USB 2.0 connectors: 1
- Number of water pump connectors: 1
- Audio connector: Yes
- Number of CPU fan connectors: 1
- Number of RGB LED pin headers: 3
- PCI-Ex1: 0
- RAM-Slots: 4
- MB-Format: micro-ATX
- Tip Memorie: DDR4
- Canale audio: N/A
- RJ-45 LAN: N/A
- Chipset audio integrat: Realtek
- USB Type C: N/A
- MB-Socket: AM5
- Format: ATX
- Recomandat Gaming: Da
- Tip slot interfata grafica: PCIe 4.0 x16
- Microphone in: Yes
- Bluetooth: Yes
- Bluetooth version: 5.4
- Ethernet LAN (RJ-45) ports: 1
- Product colour: White
- Headphone outputs: 6
- Width: 30.5 mm
- USB3: 1
- Sloturi M.2: N/A
- Soclu Procesor: NA (integrated CPU)
- Numar sloturi memorie: N/A
- Memorie maxima: 128 GB
- Model Chipset: B850
- Bluetooth: 5.4
- RJ-45: 1
- Interfata grafica: PCI Express x16 5.0
- SATA III: 4
- USB 2.0: 4
- Socket procesor: AM5
- Placa video integrata: Necesita procesor cu tehnologia AMD Radeon Graphics
- Placa audio integrata: 7.1 Audio
- Chipset: B850
- Producator chipset: AMD
- Procesoare suportate: AMD Ryzen 7000/8000/9000 Series
- Memorie Suportata: DDR5
- Capacitate maxima memorie RAM: 256 GB
- Tehnologie: Dual channel
- PCI Express 5.0: 1 (x16)
- Header USB 3.0: Da
- Suport audio: 7.1
- Dimensiuni (L x l, cm): 30.5 x 24.4 cm
- Depth: 24.4 mm
- NGFF (M.2): 3
- DisplayPort: 1
- Placa retea integrata: 2.5 Gbps
- USB 3.2 Gen2 tip A: 3
- Chipset audio: Realtek ALC897
- Chipset retea: Realtek RTL8125BG
- BIOS: SAPPHIRE CORE BIOS
- Alte specificatii: 1x PCIe 5.0 M.2, 2x PCIe 4.0 M.2
- Frecvente suportate: Pana la 8000 MHz(OC)
- PCI Express 4.0: 2 (x16) (1x x4, 1x x2)
- USB Tip C: 1x USB 3.2 Gen 2 tip C
- Audio jacks: 6
- Wireless: 802.11 a/b/g/n/ac/ax/be(2x2)
2.4 GHz / 5GHz / 6GHz - BIOS Flashback: 1
- Conectori speciali: 2× Wi Fi Antenna
Informații suplimentare
| Greutate | 2 kg |
|---|---|
| Dimensiuni | 35 × 29 × 6 cm |
| Garanție |
24 luni |
