Placa de baza Gigabyte B550M DS3H, Socket AM4
522,41 lei
100 în stoc (poate fi pre-comandat)
Placa de baza Gigabyte B550M DS3H AM4 CPU AMD Socket AM4, support for: 3rd Generation AMD Ryzen™ processors/ 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors (Please refer „CPU Support List” for more information.) Chipset AMD B550 Memory 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory 3rd Gen AMD Ryzen™ Processors: Support for DDR4 4000 (O.C.) / 3600 (O.C.) / 3333 (O.C.) /3200/2933/2667/2400/2133 MHz memory modules New Generation AMD Ryzen™ with Radeon™ Graphics processors: Support for DDR4 4733 (O.C.) / 4600 (O.C.) / 4400 (O.C.) / 4000 (O.C.) / 3600 (O.C.) / 3333 (O.C.) /3200/2933/2667/2400/2133 MHz memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer „Memory Support List” for more information.) Onboard Graphics Integrated in the 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors: 1 x DVI-D port, supporting a maximum resolution of 1920×1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR. Maximum shared memory of 16 GB Audio Realtek® ALC887 codec High Definition Audio 2/4/5.1/7.1-channel https://www.gigabyte.com/Motherboard/B550M-DS3H-rev-10/sp#sp.
- PCI: 0
- Serial-or-Paralel: No/No
- Video-Connection: DVI/HDMI
- Wi-Fi: No
- CPU încorporat: No
- Weight: 630 g
- Country of origin: China
- Warranty period: 3 year(s)
- Component for: PC
- Package width: 265 mm
- USB connector type: USB Type-A
- Ethernet interface type: Gigabit Ethernet
- Harmonized System (HS) code: 84733020
- Package height: 54 mm
- Memory channels: Dual-channel
- Ethernet LAN: Yes
- HDMI ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- HDMI version: 2.1
- Maximum internal memory: 128 GB
- Headphone outputs: 1
- Processor manufacturer: AMD
- Microphone in: Yes
- Depth: 244 mm
- Products per shipping (inner) case: 1 pc(s)
- Batteries included: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 0
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 0
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 0
- USB 2.0 ports quantity: 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- Audio output channels: 7.1 channels
- PCI Express x1 (Gen 3.x) slots: 1
- PCI Express x16 (Gen 4.x) slots: 1
- Supported storage drive types: HDD & SSD
- Supported memory types: DDR4-SDRAM
- Number of M.2 (M) slots: 2
- Processor socket: Socket AM4
- Motherboard chipset: AMD B550
- HDCP: Yes
- DVI-D ports quantity: 1
- Product colour: Brown
- VGA (D-Sub) ports quantity: 0
- Parallel processing technology support: Not supported
- DirectX version: 12.0
- Maximum resolution: 4096 x 2160 pixels
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Drivers included: Yes
- Package depth: 265 mm
- Model Chipset: B550
- Gaming: Da
- Format: Micro-ATX (mATX)
- Soclu Procesor: Socket AM4
- Tip Memorie: DDR4
- Numar sloturi memorie: 4
- Memorie maxima: 128 GB
- Tip slot interfata grafica: PCIe 4.0 x16
- Chipset audio integrat: Realtek
- Canale audio: 7.1
- Wireless: Nu
- Bluetooth: Nu
- USB Type C: Da
- HDMI: Da
- Thunderbolt: Nu
- Sloturi M.2: 2
- RJ-45 LAN: 1
- Compatible processor series: AMD Ryzen 3000 Series
- Number of memory slots: 4
- Memory slots type: DIMM
- Unbuffered memory: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 0
- Number of SATA III connectors: 4
- Number of SATA II connectors: 0
- Number of Parallel ATA connectors: 0
- Front panel audio connector: Yes
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- Number of chassis fan connectors: 2
- EPS power connector (8-pin): Yes
- PS/2 ports quantity: 1
- Motherboard form factor: micro ATX
- Motherboard chipset family: AMD
- Audio Chip: Realtek ALC887
- BIOS type: UEFI AMI
- BIOS memory size: 256 Mbit
- Clear CMOS jumper: Yes
- Width: 244 mm
- ECC сompatibility: ECC & Non-ECC
- Number of HDDs supported: 4
- Front panel connector: Yes
- TPM connector: Yes
- RGB LED pin header: Yes
- ACPI version: 5.0
- Desktop Management Interface (DMI) version: 2.7
- System Management BIOS (SMBIOS) version: 2.7
- Battery weight: 3 g
- Lithium weight per battery: 0.07 g
- Number of battery cells: 1
- Battery technology: Lithium-Manganese Dioxide (LiMnO2)
- Battery type: CR2032
- Height: 35 mm
- Maximum number of SMP processors: 1
- Discrete graphics support: Yes
- Total number of SATA connectors: 4
- 12V power connector: Yes
- Cables included: SATA
- Number of storage drives supported: 6
- Serial port headers: 1
- Supported storage drive interfaces: SATA III
- RAID levels: 0, 1, 10
- eSATA ports quantity: 0
- Firewire (IEEE 1394) ports: 0
- USB 2.0 connectors: 1
- PCI Express x16 slots: 2
- PC health monitoring: Fan, Temperature, Voltage
- Supported processor sockets: Socket AM4
- Maximum internal memory supported by processor: 128 GB
- Supported memory clock speeds: 2133,2400,2667,2933,3200,3333,3600,4000,4400,4600,4733 MHz
- Supported memory clock speed (max): 4733 MHz
- Power fan connector: Yes
- Package weight: 927 g
- Bundled software: Norton Internet Security (OEM) Realtek 8118 Gaming LAN Bandwidth Control Utility
| Greutate | 1 kg |
|---|---|
| Dimensiuni | 26,5 × 27 × 6 cm |
| Garanție |
36 luni |
Recenzii
Nu există recenzii până acum.
