Placa de baza Gigabyte AMD A520M DS3H AM4 CPU AMD Socket AM4, support for: 3rd Generation AMD Ryzen™ processors/ 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors (Please refer „CPU Support List” for more information.) Chipset AMD A520 Memory 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory 3rd Gen AMD Ryzen™ Processors: Support for DDR4 4400 (O.C.) / 4000 (O.C.) / 3600 (O.C.) / 3333 (O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules 3rd Gen AMD Ryzen™ with Radeon™ Graphics processors: Support for DDR4 4733 (O.C.) / 4600 (O.C.) / 4400 (O.C.) / 4000 (O.C.) / 3600 (O.C.) / 3333 (O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer „Memory Support List” for more information.) Onboard Graphics Integrated in the 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors: 1 x DVI-D port, supporting a maximum resolution of 1920×1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x DisplayPort, supporting a maximum resolution of 5120×2880@60 Hz * Support for DisplayPort 1.4 version, HDCP 2.3, and HDR. 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR. Support for up to 3 displays at the same time Maximum shared memory of 16 GB Audio Realtek® ALC887 codec High Definition Audio 2/4/5.1/7.1-channel https://www.gigabyte.com/Motherboard/A520M-DS3H-rev-10/sp#sp.
Placa de baza Gigabyte A520M DS3H, Socket AM4
Descriere
Caracteristici
- PCI: 0
- Serial-or-Paralel: No/No
- Video-Connection: DVI/HDMI
- Wi-Fi: No
- CPU încorporat: No
- Component for: PC
- Cooling type: Active
- USB connector type: USB Type-A
- Ethernet interface type: Gigabit Ethernet
- Windows operating systems supported: Windows 10 x64
- Harmonized System (HS) code: 84733020
- Memory channels: Dual-channel
- Ethernet LAN: Yes
- HDMI ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- HDMI version: 2.1
- Maximum internal memory: 128 GB
- Headphone outputs: 1
- Processor manufacturer: AMD
- Microphone in: Yes
- USB 2.0 ports quantity: 2
- Depth: 244 mm
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 0
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 0
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 0
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- PCI Express x1 (Gen 3.x) slots: 2
- PCI Express x16 (Gen 3.x) slots: 1
- Audio output channels: 7.1 channels
- Supported storage drive types: HDD & SSD
- Supported memory types: DDR4-SDRAM
- Processor socket: Socket AM4
- Number of M.2 (M) slots: 1
- HDCP: Yes
- DVI-D ports quantity: 1
- Digital audio optical out: 1
- DisplayPorts quantity: 1
- VGA (D-Sub) ports quantity: 0
- Drivers included: Yes
- DisplayPort version: 2.0
- Maximum resolution: 5120 x 2880 pixels
- Model Chipset: A520
- Gaming: Nu
- Format: Micro-ATX (mATX)
- Soclu Procesor: Socket AM4
- Tip Memorie: DDR4
- Numar sloturi memorie: 4
- Memorie maxima: 128 GB
- Tip slot interfata grafica: PCIe 3.0 x16
- Chipset audio integrat: Realtek
- Canale audio: 7.1
- Wireless: Nu
- Bluetooth: Nu
- USB Type C: Da
- HDMI: Da
- Thunderbolt: Nu
- Sloturi M.2: 1
- RJ-45 LAN: 1
- Number of memory slots: 4
- Memory slots type: DIMM
- Unbuffered memory: Yes
- Supported storage drive interfaces: M.2, SATA III
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 0
- Number of SATA III connectors: 4
- Number of SATA II connectors: 0
- Number of Parallel ATA connectors: 0
- Front panel audio connector: Yes
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- PS/2 ports quantity: 1
- Motherboard form factor: micro ATX
- Motherboard chipset family: AMD
- Audio Chip: Realtek ALC887
- BIOS type: UEFI AMI
- Clear CMOS jumper: Yes
- Width: 244 mm
- ECC сompatibility: ECC & Non-ECC
- Front panel connector: Yes
- TPM connector: Yes
- Power source type: ATX
- ACPI version: 5.0
- Desktop Management Interface (DMI) version: 2.7
- System Management BIOS (SMBIOS) version: 2.7
- Maximum number of SMP processors: 1
- Discrete graphics support: Yes
- Total number of SATA connectors: 4
- 12V power connector: Yes
- Clear CMOS button: Yes
- Cables included: SATA
- BIOS memory size: 128 Mbit
- Serial port headers: 1
- RAID levels: 0, 1, 10
- eSATA ports quantity: 0
- Firewire (IEEE 1394) ports: 0
- Number of HDDs supported: 5
- USB 2.0 connectors: 1
- Supported processor sockets: Socket AM4
- Maximum internal memory supported by processor: 128 GB
- Number of displays supported: 3
- Power fan connector: Yes
- Number of EATX power connectors: 1
- Bundled software: Norton® Internet Security (OEM version), Realtek® 8118 Gaming LAN Bandwidth Control Utility
- Compatible processor series: AMD Ryzen 3000 Series, AMD Ryzen Threadripper 3000 Series, AMD Ryzen Threadripper PRO 3000 WX-Series
- Supported memory clock speeds: 2133,2400,2667,2933,3200,3333,3600,4000,4400,4733 MHz
- Supported memory module capacities: 1GB, 2GB, 4GB, 8GB, 16GB, 32GB
- PC health monitoring: CPU, LED, Power supply, Temperature, Voltage
Informații suplimentare
| Greutate | 1 kg |
|---|---|
| Dimensiuni | 27 × 5 × 26 cm |
| Garanție |
36 luni |
