Placa de baza AsRock Socket AM5, X670E Steel Legend Supports
2.000,00 lei
Stoc epuizat
Descriere
Placa de baza AsRock Socket AM5, X670E Steel Legend Supports AMD Ryzen™ 7000 Series Processors 16+2+1 Phase Power Design, SPS 4 x DDR5 DIMMs, supports up to 6600+(OC) 1 PCIe 5.0 x16, 1 PCIe 3.0 x16, 1 PCIe 3.0 x1 Graphics Output Options: 1 HDMI, 1 DisplayPort 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec), Nahimic Audio 1 Blazing M.2 (PCIe Gen5x4), 3 Hyper M.2 (PCIe Gen4x4), 4 SATA3 1 USB 3.2 Gen2 Type-A (Rear), 10 USB 3.2 Gen1 (6 Rear, 4 Front), 8 USB 2.0 (4 Rear, 4 Front) Realtek 2.5G LAN, Realtek 1G LAN 802.11ax Wi-Fi 6E + Bluetooth.
Caracteristici
- PCI: 0
- Serial-or-Paralel: No/No
- Video-Connection: HDMI/DP
- Wi-FI: Yes
- Onboard-CPU: No
- RAID support: Yes
- Component for: PC
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- Memory channels: Dual-channel
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Ethernet LAN: Yes
- HDMI ports quantity: 1
- Maximum internal memory: 128 GB
- Processor manufacturer: AMD
- USB 2.0 ports quantity: 4
- PCI Express x16 (Gen 3.x) slots: 1
- Audio output channels: 7.1 channels
- PCI Express x1 (Gen 3.x) slots: 1
- Line-in: Yes
- PCI Express x16 (Gen 5.x) slots: 1
- Supported storage drive types: HDD & SSD
- Cooling type: Passive
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
- S/PDIF out port: Yes
- USB4 Gen 2x2 ports quantity: 1
- DisplayPorts quantity: 1
- DVI-D ports quantity: 0
- Parallel processing technology support: CrossFire
- Model Chipset: X670E
- Gaming: Nu
- Format: ATX
- Soclu Procesor: Socket AM5
- Tip Memorie: DDR5
- Numar sloturi memorie: 4
- Memorie maxima: 128 GB
- Tip slot interfata grafica: PCIe 5.0 x16
- Chipset audio integrat: Realtek
- Canale audio: 7.1
- Wireless: Da
- Bluetooth: Da
- USB Type C: Da
- HDMI: Da
- Thunderbolt: Nu
- Sloturi M.2: 4
- RJ-45 LAN: 2
- Number of memory slots: 4
- Memory slots type: DIMM
- Unbuffered memory: Yes
- Supported storage drive interfaces: M.2, SATA III
- USB 2.0 connectors: 2
- Front panel audio connector: Yes
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- EPS power connector (8-pin): Yes
- Motherboard chipset family: AMD
- BIOS type: UEFI AMI
- BIOS memory size: 256 Mbit
- Supported memory types: DDR5-SDRAM
- ECC сompatibility: ECC & Non-ECC
- Front panel connector: Yes
- Number of chassis fan connectors: 4
- RGB LED pin header: Yes
- Motherboard form factor: ATX
- S/PDIF out connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Number of M.2 (M) slots: 4
- RAID levels: 0, 1, 10
- Processor socket: Socket AM5
- Motherboard chipset: AMD X670
- Compatible processor series: AMD Ryzen 7000 Series
- Audio Chip: Realtek ALC1220
- Audio connector: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet, Gigabit Ethernet
- Supported memory clock speeds: 6600 MHz
- LAN controller: Dragon RTL8125BG, Realtek RTL8111
- Headphone outputs: 1
- Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
- Ethernet LAN (RJ-45) ports: 2
- Width: 244 mm
- Depth: 30.5 mm
Informații suplimentare
| Greutate | 2,55 kg |
|---|---|
| Dimensiuni | 38,5 × 10 × 32 cm |
| Garanție |
36 luni |
