Omada 32-Port 10GE L2+ Managed Switch with 24-Port PoE++ – SX3832MPP
18.668,72 lei
2 în stoc
Descriere
Omada 32-Port 10GE L2+ Managed Switch with 24-Port PoE++ PORT: 24× 10G RJ45 PoE++ Ports, 8× 10G SFP+ Slots, RJ45/USB Type C Console Port SPEC: 802.3bt/at/af (up to 90W/port), 770 W PoE Power, 1U 19″ Rack- mountable Steel Case FEATURE: Integration with Omada SDN Controller, Static Routing, DHCP Server, OAM, DDM, 802.1Q VLAN, QinQ, Fast PoE, Perpetual PoE, STP/RSTP/MSTP, IGMP Snooping, 802.1p/DSCP QoS, ACL, 802.1x, Radius/Tacacs+ Authentication, ERPS, LACP, CLI, SNMP, Dual Image/Configuration, IPv6.
Caracteristici
- Layer: Layer-2
- Stackable: No
- Stackable: Yes
- Rackable: No
- Management: Managed
- PoE: Nu
- LAN-Port-Type: 10Gigabit
- Redundant-PSU: Yes
- LAN-Ports: 16
- Storage temperature (T-T): -40 - 70 °C
- Storage relative humidity (H-H): 5 - 90%
- Product colour: Black
- Quick start guide: Yes
- Compliance certificates: CE, Federal Communications Commission (FCC), RoHS
- LED indicators: Yes
- Jumbo frames support: Yes
- Link aggregation: Yes
- Height: 44 mm
- Housing material: Metal
- Operating relative humidity (H-H): 10 - 90%
- Screws included: Yes
- AC input voltage: 110 - 240 V
- AC input frequency: 50/60 Hz
- Power over Ethernet (PoE): Yes
- Cables included: Power
- Depth: 330 mm
- Mounting brackets included: Yes
- Rack mounting: Yes
- VLAN support: Yes
- Quality of Service (QoS) support: Yes
- Static route: Yes
- Web-based management: Yes
- System event log: Yes
- Switch type: Managed
- Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
- 10G support: Yes
- Port mirroring: Yes
- Operating temperature (T-T): -5 - 45 °C
- Firmware upgradeable: Yes
- DoS attack prevention: Yes
- Access Control List (ACL): Yes
- Width: 440 mm
- Auto MDI/MDI-X: Yes
- Rate limiting: Yes
- IGMP snooping: Yes
- Auto-negotiation: Yes
- Rack mount kit: Yes
- Power supply included: No
- Configuring Location Settings (CLI): Yes
- Basic switching RJ-45 Ethernet ports quantity: 24
- Gigabit Ethernet (copper) ports quantity: 24
- Broadcast storm control: Yes
- Spanning tree protocol: Yes
- Number of queues: 8
- Multicast support: Yes
- Number of VLANs: 4000
- CPU defense: Yes
- Switch layer: L2+
- Cloud-managed: Yes
- ARP inspection: Yes
- MAC address table: 32000 entries
- Static port security: Yes
- Authentication type: AAA, RADIUS, TACACS+
- Fanless: No
- Power source: AC/PoE
- DHCP features: DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping
- IPv4 routes: 48
- IPv6 routes: 48
- Jumbo frames: 9
- Ethernet Ring Protection Switching (ERPS): Yes
- Fast Ethernet (copper) ports quantity: 24
- Rubber feet: Yes
- Number of fans: 4 fan(s)
- Switching capacity: 640 Gbit/s
- MIB support: RFC1213, RFC2233, RFC1643, RFC1493, RFC2674, RFC2819, RFC2021, RFC2620, RFC2618, RFC2925
- Console port: RJ-45/USB Type-C
- 2.5G Ethernet (copper) ports quantity: 24
- Packet buffer memory: 24 MB
- Authentication: Guest VLAN
- Porturi RJ 45: 24-28
- Viteza transfer: 10G+
- Porturi SFP: peste 9
- Montare in Rack: Da
- Forwarding rate: 240 Mpps
- Unified static configuration: Yes
- Installed SFP+ modules quantity: 8
- 10G Ethernet (copper) ports quantity: 24
- Address Resolution Protocol (ARP) entries (max): 510
- Virtual LAN features: MVRP, Private VLAN, SSID-based VLAN assignment, VLAN Identifier ( VLAN ID), Voice VLAN
- Security algorithms: HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSL/TLS
- Queue scheduling algorithms: Strict Priority Queue (SPQ), WRR+SP, Weighted Round Robin (WRR)
- Multicast Listener Discovery (MLD) snooping: Yes
- Device link detection protocol (DLDP): Yes
- IPv4 & IPv6 features: Dual stack IPv4/IPv6, IPv6 SNMP, IPv6 SSH, IPv6 TFTP, IPv6 Telnet, IPv6 ping, IPv6 tracert
- Form factor: DIN rail
- Power consumption (typical): 953.7 W
- Power consumption (max): 1010.2 W
- Power saving mode (EEE): Yes
- Power over Ethernet 4PPoE (PoE++) ports quantity: 24
- Power over Ethernet (PoE) power per port: 90 W
- Total Power over Ethernet (PoE) budget: 770 W
- Packaging content: Console Cable
- Heat dissipation: 3444.7 BTU/h
- Sustainability organizations: Accountability
Informații suplimentare
| Greutate | 6 kg |
|---|---|
| Dimensiuni | 53 × 48 × 10 cm |
| Garanție |
5 ani |
