DeltaStream 4-port Pizza-box GPON Optical Line Terminal – DS-P7001-04
5.295,00 lei
2 în stoc
Descriere
DeltaStream 4-port Pizza-box GPON Optical Line Terminal • 4× 2.5G PON Ports • 1× 10 Gbps SFP+ Uplink Port • 1× 10/100/1000 Mbps RJ45 Uplink Port • 1× RJ45 Console Port • 1× RJ45 MGMT Port • 1× Alarm Port (Reserved) Max. 58W • IEEE 802.1p/DSCP QoS • Voice VLAN • Auto VoIP.
Caracteristici
- Storage relative humidity (H-H): 5 - 90%
- DHCP server: Yes
- Quality of Service (QoS) support: Yes
- Static route: Yes
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- Multicast Listener Discovery (MLD) snooping: Y
- Operating relative humidity (H-H): 10 - 90%
- Ethernet LAN (RJ-45) ports: 2
- Operating temperature (T-T): 0 - 50 °C
- Depth: 180 mm
- Storage temperature (T-T): -40 - 70 °C
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Width: 440 mm
- Power consumption (max): 58 W
- Height: 44 mm
- SFP/SFP+ slots quantity: 1
- DHCP relay: Yes
- GPON split ratio (max): 1:128
- Maximum operating distance (GPON): 20000 m
- Upstream ports: Gigabit Ethernet
- GPON ports quantity: 4
- DC voltage range: 38.4 - 72 V
- Numar usi: N/A
- Interfata retea: 10/100/1000Mbps
- Relee: 1
- Intrare contact usa: 1
- Intrare buton cerere iesire: N/A
- Intrare alarma: 1
- Iesire alarma: 1
- Alimentare: 100-240Vca
- Configurare WEB browser: Da
- Wiegand: Nu
- RS-485: Nu
- OSDP: Nu
- USB: Nu
- Contact sabotaj: Nu
Informații suplimentare
| Greutate | 2,037 kg |
|---|---|
| Dimensiuni | 34,5 × 25 × 9 cm |
| Garanție |
36 luni |
