Nou
CUDY 5-Port 10/100/1000M PoE+ Switch 120W, 4-Port 10/100/1000M PoE+ – GS1005PTS1
222,00 lei
5 în stoc
Descriere
CUDY 5-Port 10/100/1000M PoE+ Switch 120W, 4-Port 10/100/1000M PoE+ ports, 60 watts for port #1, 802.3at/af, VLAN ON/OFF, Extend ON/OFF, Watchdog ON/OFF, Fanless, ±4KV Surge Protection, Watchdog, 120W Internal Power Supply.
Caracteristici
- Layer: Layer-2
- Stackable: No
- Rackable: No
- Management: Unmanaged
- PoE: Nu
- LAN-Port-Type: Gigabit
- Redundant-PSU: No
- LAN-Ports: 5
- Storage relative humidity (H-H): 5 - 90%
- Products per master (outer) case: 20 pc(s)
- Package type: Box
- Product colour: Black
- Manual: Yes
- Storage temperature (T-T): -40 - 85 °C
- Plug and Play: Yes
- Weight: 600 g
- Jumbo frames support: Yes
- Depth: 118 mm
- Height: 44 mm
- Housing material: Metal
- Power supply included: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- Operating relative humidity (H-H): 10 - 90%
- Cables included: AC
- Operating altitude: 0 - 3048 m
- Package weight: 900 g
- Wall mountable: Yes
- Package depth: 190 mm
- AC input voltage: 100 - 240 V
- Power over Ethernet (PoE): Yes
- Package height: 60 mm
- Width: 200 mm
- Package width: 245 mm
- Full duplex: Yes
- Rack mounting: Yes
- VLAN support: Yes
- Installed SFP modules quantity: 1
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Flow control support: Yes
- Mean time between failures (MTBF): 100000 h
- Operating temperature (T-T): -20 - 50 °C
- Master (outer) case length: 320 mm
- Master (outer) case width: 505 mm
- Power source: AC
- Installed SFP+ modules quantity: 1
- Master (outer) case net weight: 19 kg
- Half duplex: Yes
- Basic switching RJ-45 Ethernet ports quantity: 5
- Jumbo frames: 9216
- LED indicators: Activity, Link, Power
- Fanless: Yes
- MAC address table: 2000 entries
- Fiber type: Multi-mode
- Input current: 1.25 A
- Power over Ethernet (PoE) ports quantity: 4
- Power over Ethernet (PoE) power per port: 30 W
- Store-and-forward: Yes
- Power connector: AC-in jack
- Packet buffer memory: 1 MB
- Total Power over Ethernet (PoE) budget: 120 W
- Switching capacity: 12 Gbit/s
- Combo SFP ports quantity: 1
- Power over Ethernet plus (PoE+) ports quantity: 1
- Switching optical modules type: Gigabit Ethernet
- Uplink ports quantity: 1
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- Output current: 1.25 A
- Porturi RJ 45: 5-10
- Viteza transfer: Gigabit
- Porturi SFP: 1-2
- Montare in Rack: Da
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-TX
- Cable types supported: Cat3, Cat4, Cat5, Cat5e, Cat6, Cat6+, Cat6a, Cat6e, Cat7, Cat7e, Cat8, Cat8.1
- Throughput: 8.928 Mpps
- Output voltage: 52 V
- Master (outer) case height: 402 mm
Informații suplimentare
| Greutate | 0,954 kg |
|---|---|
| Dimensiuni | 24,5 × 19 × 6 cm |
| Garanție |
24 luni |
