B850 GAMING PLUS WIFI6E
909,00 lei
Disponibil pentru pre-comenzi
Descriere
Placă de bază GIGABYTE B850 GAMING PLUS WIFI6E, ATX, socket AM5, chipset B850, suport DDR5 192 GB, PCIe 4.0 x16, M.2 Gen4, WiFi 6E, LAN 2.5 Gbps.
Caracteristici
- PCI: 0
- Serial-or-Paralel: No/No
- Video-Connection: None
- Wi-FI: Yes
- USB3: 4-8
- PCI-Ex1: 1
- PCI-Ex16: 1
- Onboard-CPU: No
- RAID support: Yes
- Component for: PC
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- Memory channels: Dual-channel
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Ethernet LAN: Yes
- HDMI ports quantity: 1
- HDMI version: 2.1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
- Processor manufacturer: AMD
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 0
- USB 2.0 ports quantity: 4
- Audio output channels: 7.1 channels
- PCI Express x16 (Gen 5.x) slots: 1
- Audio Chip: Realtek ALC897
- PCI Express x16 (Gen 4.x) slots: 1
- On-board graphics card: No
- Supported storage drive types: HDD & SSD
- DisplayPort version: 1.2
- DisplayPorts quantity: 1
- VGA (D-Sub) ports quantity: 0
- DVI-D ports quantity: 0
- Model Chipset: B850
- Gaming: Da
- Format: ATX
- Soclu Procesor: Socket AM5
- Tip Memorie: DDR5
- Numar sloturi memorie: 4
- Memorie maxima: 256 GB
- Tip slot interfata grafica: PCIe 5.0 x16
- Chipset audio integrat: Realtek
- Canale audio: 7.1
- Wireless: Da
- Bluetooth: Da
- HDMI: Da
- Thunderbolt: Nu
- Sloturi M.2: 3
- RJ-45 LAN: 1
- Number of memory slots: 4
- Memory slots type: DIMM
- Number of SATA III connectors: 4
- Number of SATA II connectors: 0
- Number of SATA connectors: 0
- CPU fan connector: Yes
- Motherboard chipset family: AMD
- BIOS type: UEFI AMI
- mSATA ports quantity: 0
- Supported memory types: DDR5-SDRAM
- Maximum internal memory: 256 GB
- Number of HDDs supported: 4
- Number of storage drives supported: 7
- RAID levels: 0, 1, 5, 10
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- RGB LED pin header: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
- Motherboard form factor: ATX
- Windows operating systems supported: Windows 11 x64
- Number of M.2 (M) slots: 3
- 1st M.2 highest PCI Express generation: 5.0
- 2nd M.2 largest key size: 22110
- 2nd M.2 highest PCI Express generation: 4.0
- 3rd M.2 highest PCI Express generation: 4.0
- Total number of SATA connectors: 4
- ECC сompatibility: Non-ECC
- S/PDIF out connector: Yes
- Processor socket: Socket AM5
- Supported processor sockets: Socket AM5
- Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- Motherboard chipset: AMD B850
- 1st M.2 largest key size: 2280
- 3rd M.2 largest key size: 2280
- USB 2.0 connectors: 4
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
- Supported memory clock speed (max): 8200 MHz
- Maximum internal memory supported by processor: 256 GB
- Number of water pump connectors: 1
- PCI Express x16 (Gen 3.x) slots: 2
- Number of RGB LED pin headers: 3
- Supported storage drive interfaces: M.2, Micro SATA III
- ACPI version: 6.5
- System Management BIOS (SMBIOS) version: 3.7
- MB-Format: ATX
- RAM-Slots: 4
- USB Type C: N/A
- MB-Socket: AM5
- Number of CPU fan connectors: 4
- LAN controller: Realtek RTL8125D
- Bluetooth: Yes
- Product colour: Black
- Bluetooth version: 5.3
- Ethernet LAN (RJ-45) ports: 1
- Width: 243.8 mm
- Depth: 304.8 mm
- Supported memory clock speeds: 4800,5600,6400,8200 MHz
Informații suplimentare
| Greutate | 1,715 kg |
|---|---|
| Dimensiuni | 34 × 27 × 7 cm |
| Garanție |
36 luni |
